256-BIT
ADVANCED MEMORY INTERFACE
•
Wider memory data path with next generation controller technology
for superior performance throughput.
NVIDIA
CINEFX 2.0 ENGINE
•
Advanced pixel shaders deliver 2x the floating-point shader
pixel performance of previous generations
•
Support for Microsoft® DirectX® 9.0 (DX9) pixel shader
2.0+
•
Support for DX9 vertex shader 2.0+
•
Long pixel programs up to 1,024 instructions
•
Long vertex programs up to 256 static instructions with up
to 65,536 instructions executed
•
Dynamic, conditional execution and flow control
•
Architected for Cg and Microsoft HLSL for maximum compatability
for next-generation content
•
128-bit, studio-quality, floating-point precision computation
through the entire rendering pipeline
•
Native hardware support for 32 bpp, 64 bpp, and 128 bpp rendering
modes
•
Up to 12 pixel shader operations per clock
•
Up to 16 texture shader operations per clock
•
Support for sRGB texture format for gamma textures
•
DirectX and S3TC texture compression
•
Optimized for 32-, 24-, 16-, 15-, and 8-bpp modes
•
True-color, 64x64 hardware cursor alpha
•
Multibuffering (double, triple or quad) for smooth animation
and video playback.
INTELLISAMPLE
HCT TECHNOLOGY
•
Increased visual quality at higher resolutions through advances
in compression, anistropic filtering, and antialiasing technology
•
Blistering-fast antialiasing and compression performance
•
Support for advanced lossless compression algorithms for both
color, texture, and z data at even higher resoltuions and
frame rates
•
Fast x-clear |
|
ULTRASHADOW
TECHNOLOGY •
Accelerates shadow volumes for next-generation games
•
Accurately maintains shadows while discarding non-useful information
ADVANCED DISPLAY PIPELINE •
Integrated NTSC/PAL TV encoder supporting resolutions up to
1024x768 without the need for panning with built-in Macrovision
copy protection
•
DVD and HDTV-ready MPEG-2 decoding up to 1920x1080i resoltions
•
Dual, integrated 400 MHz RAMDACs for display resolutions up
to and including 2048x1536@85 Hz
•
Dual DVO ports for interfacing to txternal TMDS transmitters
•
Internal TV support
•
VIP 1.1 interface support for Video In function
•
Microsoft Video Mixing Renderer (VMR) support for multiple
video windows with full video quality and features in each
window
NVIDIA
DIGITAL VIBRANCE CONTROL 3.0
•
DVC image sharpening controls
•
DVC color controls
ADVANCED
TECHNOLOGY
•
AGP 8X including Fast-Writes and sideband addressing
•
0.13-micron precess technology for higher levels of integration
and higher operating clock speeds
•
Advanced thermal management and thermal monitoring
•
40 mm x 40 mm, BGA 1309 flip-chip package
OPERATING
SYSTEM SUPPORT
•
Microsoft Windows® XP
•
Windows ME
•
Windows 2000
•
Windows 9x
API
SUPPORT
•
Comprehensive Microsoft DirectX 9.0 (and lower) support
•
OpenGL 1.4 (and lower) support
|
